| Multi-Purpose Transformers SINGLE | 500 mW. 6 Pin Thru hole
|
|
| Multi-Purpose Transformers SINGLE | 500 mW. 6 Pin Surface Mount
|
|
| Multi-Purpose Transformer SCHEMATICS | Additional winding configurations
available for the 500 mW 6 pin style. |
|
| Multi-Purpose Transformers | 250 mW. 14 Pin Triple
Thru hole and SM |
|
| Multi-Purpose Transformers | 250 mW. 8 Pin Triple
Thru hole and SM |
|
| Additional Multi-Purpose Transformers Not listed in catalog sheets above. | ||
| T-1152 | 1:1.37 Turns Ratio. 600 mH. EP Style | |
| T-969 | 1 : 0.5 : 0.5 Turns Ratio. 12 mH. EP Style. | |
| T-927 | 1 : 1 Turns Ratio, 5 mH, 500 VmS | |
| T-924 | 1 : 1 :1 Turns Ratio. 4 mH, 240 VmS | |
| T-925 | High Isolation (4K VRMS) version of the T-924 | |
| T-970 | 1 : 1 :1 Turns Ratio. 3 mh, 200 VmS. EP Style. | |
| T-1149 | 1 : 1CT, 600 mH. EP Style | |
| T-704 | 4 : 1 :1 Turns Ratio. 800 mH, 6 Pin Thru Hole. | |
| T-705 | 40 : 1 :1 Turns Ratio. 19 mH, 6 Pin Thru Hole. | |
