TRANSFORMERS for
PMC-SIERRA PM6341
Integrated Circuit

These Data Sheets are in Adobe Acrobat Format.


Description
Rhombus
Part #
Part #
Description
E1
 T-10213
TX, Single TH
 T-10313
TX, Single SM
 T-10215
RX, Single TH
 T-10315
RX, Single SM
 T-10149
14 Pin Dual TH, TX & RX
 T-11049
SM Version of T-10149
 T-14401
12 Pin Dual SM, TX & RX
T-14115
16 Pin Dual SM TX & RX
50 mil SOIC package
Standard Temp. Range Only!
0 to 70o C
T-13635
TX, Single TH, 3 KVRMS
Reinforced insulation
T-13635G
TX, Single SM, 3 KVRMS
Reinforced insulation
T-13614
RX, Single TH, 3 KVRMS
Reinforced insulation
 T-13614G
RX, Single SM, 3 KVRMS
Reinforced insulation
 T-15801
Dual TH, TX & RX
3KV (Reinforced insulation)
T-15801G
Dual SM, TX & RX
3KV (Reinforced insulation)
                     TX = Transmit      RX = Receive
                     TH = Thru Hole    SM = Surface Mount
